F46P WASTEGATE
The F46P replaces the legacy-model F46, and is unique in that it is the only aftermarket replacement for the O.E. Porsche 924, 911, 930 and 964 Turbo model wastegates. Exhaust flanges are a direct replacement. Boost pressure (air) lines will require retrofit.
The F46P has a revised lower housing which provides for clearance on all of the above models, even those with aftermarket exhaust systems.
Technical Specifications:
- High temp based alloy valve with a wear resistant coating offers longer product life compared to competing designs.
- High temperature silicone reinforced actuator diaphragm.
- Stainless steel actuator spring gives consistent force at high temperature.
- Stainless Steel is used for the valve seat, and valve bushing.
- All Stainless Steel hardware.
- Mating weld flanges are 304L.
- M10 air signal ports for easy install.
Included in the package:
- F46P wastegate assembly
- Installation gaskets
- All air fittings, CNC machined in-house, from stainless steel and aluminum.
- Weld flanges sold separately.
| Item# | Description | Qty. | Price | |
|---|---|---|---|---|
| 002718 | Wastegate 46mm P956/962 1.0 Bar (14.50 psi) Silver | $570.15 | ||
| 002719 | Wastegate 46mm P956/962 1.0 Bar (14.50 psi) Blue | $570.15 | ||
| 002720 | Wastegate 46mm P956/962 1.0 Bar (14.50 psi) Black | $570.15 | ||
| 002721 | Wastegate 46mm P956/962 1.0 Bar (14.50 psi) Purple | $570.15 | ||
| 002722 | Wastegate 46mm P956/962 1.0 Bar (14.50 psi) Red | $570.15 | ||
| 002723 | Wastegate 46mm Porsche 1.1 Bar (15.95 psi) Silver | $570.15 | ||
| 002724 | Wastegate 46mm Porsche 1.1 Bar (15.95 psi) Blue | $570.15 | ||
| 002725 | Wastegate 46mm Porsche 1.1 Bar (15.95 psi) Black | $570.15 | ||
| 002726 | Wastegate 46mm Porsche 1.1 Bar (15.95 psi) Purple | $570.15 | ||
| 002727 | Wastegate 46mm Porsche 1.1 Bar (15.95 psi) Red | $570.15 | ||
| 002728 | Wastegate 46mm Porsche 1.2 Bar (17.40 psi) Silver | $570.15 | ||
| 002729 | Wastegate 46mm Porsche 1.2 Bar (17.40 psi) Blue | $570.15 | ||
| 002730 | Wastegate 46mm Porsche 1.2 Bar (17.40 psi) Black | $570.15 | ||
| 002731 | Wastegate 46mm Porsche 1.2 Bar (17.40 psi) Purple | $570.15 | ||
| 002732 | Wastegate 46mm Porsche 1.2 Bar (17.40 psi) Red | $570.15 | ||
| 002733 | Wastegate 46mm Porsche 1.3 Bar (18.85 psi) Silver | $570.15 | ||
| 002734 | Wastegate 46mm Porsche 1.3 Bar (18.85 psi) Blue | $570.15 | ||
| 002735 | Wastegate 46mm Porsche 1.3 Bar (18.85 psi) Black | $570.15 | ||
| 002736 | Wastegate 46mm Porsche 1.3 Bar (18.85 psi) Purple | $570.15 | ||
| 002737 | Wastegate 46mm Porsche 1.3 Bar (18.85 psi) Red | $570.15 | ||
| 002738 | Wastegate 46mm Porsche 1.4 Bar (20.30 psi) Silver | $570.15 | ||
| 002739 | Wastegate 46mm Porsche 1.4 Bar (20.30 psi) Blue | $570.15 | ||
| 002740 | Wastegate 46mm Porsche 1.4 Bar (20.30 psi) Black | $570.15 | ||
| 002741 | Wastegate 46mm Porsche 1.4 Bar (20.30 psi) Purple | $570.15 | ||
| 002742 | Wastegate 46mm Porsche 1.4 Bar (20.30 psi) Red | $570.15 | ||
| 001708 | Wastegate 46mm Porsche .2 Bar (2.90 psi) Silver | $539.70 | ||
| 002679 | Wastegate 46mm Porsche .2 Bar (2.90 psi) Blue | $539.70 | ||
| 002680 | Wastegate 46mm Porsche .2 Bar (2.90 psi) Black | $539.70 | ||
| 002681 | Wastegate 46mm Porsche .2 Bar (2.90 psi) Purple | $539.70 | ||
| 002682 | Wastegate 46mm Porsche .2 Bar (2.90 psi) Red | $539.70 | ||
| 002683 | Wastegate 46mm Porsche .3 Bar (4.35 psi) Silver | $539.70 | ||
| 002684 | Wastegate 46mm Porsche .3 Bar (4.35 psi) Blue | $539.70 | ||
| 002685 | Wastegate 46mm Porsche .3 Bar (4.35 psi) Black | $539.70 | ||
| 002686 | Wastegate 46mm Porsche .3 Bar (4.35 psi) Purple | $539.70 | ||
| 002687 | Wastegate 46mm Porsche .3 Bar (4.35 psi) Red | $539.70 | ||
| 002688 | Wastegate 46mm Porsche .4 Bar (5.80 psi) Silver | $539.70 | ||
| 002689 | Wastegate 46mm Porsche .4 Bar (5.80 psi) Blue | $539.70 | ||
| 002690 | Wastegate 46mm Porsche .4 Bar (5.80 psi) Black | $539.70 | ||
| 002691 | Wastegate 46mm Porsche .4 Bar (5.80 psi) Purple | $539.70 | ||
| 002692 | Wastegate 46mm Porsche .4 Bar (5.80 psi) Red | $539.70 | ||
| 002693 | Wastegate 46mm Porsche .5 Bar (7.25 psi) Silver | $539.70 | ||
| 002694 | Wastegate 46mm Porsche .5 Bar (7.25 psi) Blue | $539.70 | ||
| 002695 | Wastegate 46mm Porsche .5 Bar (7.25 psi) Black | $539.70 | ||
| 002696 | Wastegate 46mm Porsche .5 Bar (7.25 psi) Purple | $539.70 | ||
| 002697 | Wastegate 46mm Porsche .5 Bar (7.25 psi) Red | $539.70 | ||
| 002698 | Wastegate 46mm Porsche .6 Bar (8.70 psi) Silver | $539.70 | ||
| 002699 | Wastegate 46mm Porsche .6 Bar (8.70 psi) Blue | $539.70 | ||
| 002700 | Wastegate 46mm Porsche .6 Bar (8.70 psi) Black | $539.70 | ||
| 002701 | Wastegate 46mm Porsche .6 Bar (8.70 psi) Purple | $539.70 | ||
| 002702 | Wastegate 46mm Porsche .6 Bar (8.70 psi) Red | $539.70 | ||
| 002703 | Wastegate 46mm Porsche .7 Bar (10.15 psi) Silver | $539.70 | ||
| 002704 | Wastegate 46mm Porsche .7 Bar (10.15 psi) Blue | $539.70 | ||
| 002705 | Wastegate 46mm Porsche .7 Bar (10.15 psi) Black | $539.70 | ||
| 002706 | Wastegate 46mm Porsche .7 Bar (10.15 psi) Purple | $539.70 | ||
| 002707 | Wastegate 46mm Porsche .7 Bar (10.15 psi) Red | $539.70 | ||
| 002708 | Wastegate 46mm Porsche .8 Bar (11.60 psi) Silver | $539.70 | ||
| 002709 | Wastegate 46mm Porsche .8 Bar (11.60 psi) Blue | $539.70 | ||
| 002710 | Wastegate 46mm Porsche .8 Bar (11.60 psi) Black | $539.70 | ||
| 002711 | Wastegate 46mm Porsche .8 Bar (11.60 psi) Purple | $539.70 | ||
| 002712 | Wastegate 46mm Porsche .8 Bar (11.60 psi) Red | $539.70 | ||
| 002713 | Wastegate 46mm Porsche .9 Bar (13.05 psi) Silver | $539.70 | ||
| 002714 | Wastegate 46mm Porsche .9 Bar (13.05 psi) Blue | $539.70 | ||
| 002715 | Wastegate 46mm Porsche .9 Bar (13.05 psi) Black | $539.70 | ||
| 002716 | Wastegate 46mm Porsche .9 Bar (13.05 psi) Purple | $539.70 | ||
| 002717 | Wastegate 46mm Porsche .9 Bar (13.05 psi) Red | $539.70 |
