F41 WASTEGATE
Technical Specifications:
- High temp based alloy valve housing will offer longer product life compared to competing designs.
- High temperature silicone reinforced actuator diaphragm.
- Stainless steel actuator spring gives consistent force at high temperature.
- Wear resistant Stainless Steel is used for the valve seat, and valve bushing.
- All Stainless Steel hardware.
- Mating weld flanges are 304L.
- M10 air signal ports for easy install.
- Compact design fits in very tight spaces.
Included in the package:
- F41 wastegate assembly
- All air fittings, CNC machined in-house, from stainless steel and aluminum.
- Weld flanges sold separately.
| Item# | Description | Qty. | Price | |
|---|---|---|---|---|
| 002809 | Wastegate 41mm .3 bar (3.63 psi) Silver | $317.70 | ||
| 002811 | Wastegate 41mm .3 bar (3.63 psi) Black | $317.70 | ||
| 002814 | Wastegate 41mm .4 bar (5.80 psi) Silver | $317.70 | ||
| 002816 | Wastegate 41mm .4 bar (5.80 psi) Black | $317.70 | ||
| 002819 | Wastegate 41mm .5 bar (7.25 psi) Silver | $317.70 | ||
| 002821 | Wastegate 41mm .5 bar (7.25 psi) Black | $317.70 | ||
| 002824 | Wastegate 41mm .6 Bar (8.70 psi) Silver | $317.70 | ||
| 002826 | Wastegate 41mm .6 Bar (8.70 psi) Black | $317.70 | ||
| 002829 | Wastegate 41mm .7 bar (10.15 psi) Silver | $317.70 | ||
| 002831 | Wastegate 41mm .7 bar (10.15 psi) Black | $317.70 | ||
| 002834 | Wastegate 41mm .8 Bar (11.60 psi) Silver | $317.70 | ||
| 002836 | Wastegate 41mm .8 Bar (11.60 psi) Black | $317.70 | ||
| 002839 | Wastegate 41mm .9 Bar (13.05 psi) Silver | $317.70 | ||
| 002841 | Wastegate 41mm .9 Bar (13.05 psi) Black | $317.70 | ||
| 002844 | Wastegate 41mm 1.0 Bar (14.50 psi) Silver | $317.70 | ||
| 002846 | Wastegate 41mm 1.0 Bar (14.50 psi) Black | $317.70 | ||
| 002849 | Wastegate 41mm 1.1 Bar (15.95 psi) Silver | $332.10 | ||
| 002851 | Wastegate 41mm 1.1 Bar (15.95 psi) Black | $332.10 | ||
| 002854 | Wastegate 41mm 1.2 Bar (17.40 psi) Silver | $332.10 | ||
| 002856 | Wastegate 41mm 1.2 Bar (17.40 psi) Black | $332.10 | ||
| 002859 | Wastegate 41mm 1.3 Bar (18.85 psi) Silver | $332.10 | ||
| 002861 | Wastegate 41mm 1.3 Bar (18.85 psi) Black | $332.10 | ||
| 002864 | Wastegate 41mm 1.4 Bar (20.30 psi) Silver | $332.10 | ||
| 002866 | Wastegate 41mm 1.4 Bar (20.30 psi) Black | $332.10 | ||
| 002869 | Wastegate 41mm 1.5 Bar (21.75 psi) Silver | $332.10 | ||
| 002871 | Wastegate 41mm 1.5 Bar (21.75 psi) Black | $332.10 | ||
| 002874 | Wastegate 41mm 1.6 Bar (23.20 psi) Silver | $332.10 | ||
| 002876 | Wastegate 41mm 1.6 Bar (23.20 psi) Black | $332.10 |
